Deployable Clinic Pods

Flexipod Clinic integrates a fully equipped, protected medical facility inside a standard 20‑foot ISO container, ready to transport by land, sea or air and operate off‑grid with integral power and medical‑grade HVAC.

Why organisations choose this clinic

• ROLE 2 capability in a ROLE 1 environment: fully equipped medical and surgical space with hybrid MEDEVAC/CASEVAC workflows.
• Off‑grid & self‑sufficient: 15 kWh or 20 kWh energy package with grid (230/400 V), hybrid generator (petrol/LPG) and flexible solar panels.
• Protected care: ballistic protection (STANAG 2920; extended options to STANAG 4569), enhanced counter‑drone features, low IR/EMS options and CBRN/COLPRO‑compliant positive‑pressure ventilation.
• Clinical design for IPC: compliant floor drainage, medical workstation, storage with dual refrigerators and medical‑grade HVAC.
• Rapidly deployable: standard 20‑ft ISO interface; flatbed/forklift handling; airlift by C‑130 (2 units) or CH‑47 (underslung); road & sea transport.

Technical highlights

• HVAC: CBRN/COLPRO compliant (Dantherm), positive pressurisation; operating ranges — cooling +20 °C to +60 °C, heating −32 °C to +20 °C; HEPA filter available.
• Lighting: fixed & surgical lights (BOS Defence & Security) with white/green/blue modes.
• iNTRAXX wall system: wall‑mounted ambulance system; G‑force certified 10/26 G.
• Insulation: thermal conductivity λ = 0.022; wall 65 mm, ceiling 100 mm, floor 65 mm.

Dimensions

• Interior (L × W × H): 5898 mm × 2352 mm × 2393 mm
• Exterior (L × W × H): 6058 mm × 2438 mm × 2591 mm

Frequently asked questions

How is it powered off‑grid?

The clinic includes a 15 kWh or 20 kWh energy package with grid charging (230/400 V; 110 V optional), hybrid generator compatibility (petrol/LPG) and flexible solar panels.

What protection does the structure provide?

Ballistic protection to STANAG 2920 (with extended options to STANAG 4569), CBRN/COLPRO‑compliant HVAC with positive pressure, plus options for low IR/EMS signatures and hybrid warfare camouflage.

How is it transported?

Standard 20‑ft ISO interface for flatbed and forklift handling; road & sea compatible; air transport includes C‑130 (2 units) and CH‑47 underslung loads

Standards & certifications

• CSC Convention (1972) — safety certification for international transport
• ISO 668 — classification & dimensions for standard freight ISO containers
• EN 15218; EN 14509; EN 60364; IEC 62391
• EN 1253 — hygienic floor drainage (IPC)
• IEC 61010‑1; EN 61000 (EMC add‑on); EN 60601‑1
• EN 13795 / EN 14683 — infection control & hygiene
• CBRN/COLPRO ventilation
